Item	Specification
Working weight - a.	2260 kg (5000 lb)
Impact rate - b.	360-520 bpm
Operating pressure -c.	130-140 bar (1890-2030 psi)
Pressure relief, min - d.	185 bar (2680 psi)
Pressure relief, max	220 bar (3190 psi)
Oil flow range	160-230 l/min (42-60 gal/min)
Back pressure, max	5 bar (73 psi)
Input power	54 kW (73 HP)
Tool diameter	140 mm (5.51 in)
Pressure line connection (IN)	SAE 6000 psi 1 "
Return line connection (OUT)	SAE 6000 psi 1 1/4 "
Pressure line size (minimum inner diameter)	26mm(1in)
Return line size (minimum inner diameter	32 mm (1.26 in)
Optimumoiltemperature	+40 - +60°C (+104 - +140°F)
Allowed oil temperature range	-20 - +80°C (-4 - +176°F)
Optimum oil viscosity at operating temperature	30-60 cSt
Allowed oil viscosity range	20-1000 cSt
Carrier weight - e.	25-40 ton (55000-88000 lb)
Noise level	85 dB(A)/35-50 m (115-165 ft)
a. Includes average mounting bracket and standard tool
b. Actual impact frequency depends on oil flow, oil viscosity, temperature, and material to be broken
c. Actual pressure depends on oil flow, oil viscosity, temperature, material to be broken and back pressure
d. Minimum setting = actual operating pressure + 50 bar (730 psi)
e. Check carrier's lifting capacity from carrier manufacturer
